Tig Wire ER308Lsi Stainless Steel
PRODUCT ENQUIRY
Description
TIGarc ER308LSi Stainless Steel Tig Wires.
AWS A5.9 : ER308LSi
AS/NZS:14343 B-SS308LSi
Features and Benefits
TIGarc ER308Lsi is a Stainless Steel Tig Wire Used principally for welding austenitic materials containing Low carbon.
Used mostly for welding 304 stainless steel the 0.65-1.20% silicon content improves wetting behaviour in the Argon gas shielded welding process.
Also suitable for the general welding of 301, 302, 304, 321, 347, 409, and 444 series Stainless Steel.
Used as a filler material when welding type 304 stainless. 308 grade contains 20% chromium and 11% nickel
Suitable flow rates of shielding gas are in the range of 7-15 l/min at 30-200A and 12-20 l/min at 100-300A in manual GTAW
MECHANICAL PROPERTIES:
Yield Strength:- 206 MPa min
Tensile Strength:- 585 MPa min
Elongation 40%
DC-EN
100% Argon
All Position welding
1000mm Long Lengths
Carbon:- 0.8 max
Chromium:- 19.0 – 21.0
Nickel:- 10.0 – 12.0
Manganese:- 2.0 max
Silicon:- 0.75 max
Phosphorus:- 0.045 max
